Modular Data Lakehouse Platform for Cloud-Native Apache Spark Workloads

Ilum is an Apache Spark management platform designed for Kubernetes e Apache Hadoop Yarn environments. It provides enterprise-grade cluster orchestration, interactive Spark sessions via REST API , and seamless integration with modern data engineering tools including Jupyter , Fluxo de ar Apache , Fluxo de ML e Lago Delta / Icebergue / Hudi table formats.

Key Capabilities​

• Kubernetes-native Spark operator with automatic pod orchestration and resource management
• Multi-cluster management across cloud providers (GKE, EKS, AKS) and on-premise deployments
• Interactive Spark sessions accessible through REST API endpoints for building Spark-based microservices
• Apache Hadoop Yarn integration for hybrid cluster architectures
• Built-in S3-compatible object storage for cloud-native data lake architectures
• Horizontal scalability from single-node development to production clusters with hundreds of executors

Get started with Ilum →| View architecture documentation →

Ilum - Apache Spark on Kubernetes Platform​

Ilum transforms Apache Spark cluster management by providing a unified control plane for Kubernetes e Fio -based Spark deployments. Unlike traditional Spark management approaches, Ilum treats Spark applications as first-class microservices with REST API interfaces, enabling real-time data processing architectures.

Arquitetura ​

Ilum's architecture consists of two core components:

1. Núcleo de Ilum : Backend service providing gRPC/Kafka-based job orchestration, cluster state management, and REST API endpoints
2. Ilum UI : Web-based dashboard for cluster monitoring, job submission, and resource visualization

The platform supports both Pitão (PySpark) and Scala programming languages, with native integration for Spark SQL , Spark Streaminge MLlib frameworks.

Data Lakehouse Capabilities​

Ilum provides comprehensive support for modern table formats:

• Lago Delta : ACID transactions with time travel and schema evolution
• Apache Iceberg : Partition evolution and hidden partitioning for large-scale analytics
• Apache Hudi : Record-level upserts and incremental data processing
• Mesas Ilum : Unified API abstraction across multiple table formats

Integration with Hive Metastore e Nessie catalog enables SQL-based metadata management and Git-like data versioning.

REST API for Spark Microservices​

Ilum exposes Spark functionality through RESTful endpoints:

# Submit Spark job
POST /api/v1/jobs

# Query interactive session
POST /api/v1/sessions/{id}/execute

# Monitor job status
GET /api/v1/jobs/{id}/status

This enables building responsive data applications where Spark computations are triggered by HTTP requests, supporting use cases like:

• Real-time feature engineering for ML models
• On-demand data transformations via API
• Streaming analytics with REST-based controls
• Jupyter notebook execution through HTTP interface

Multi-Cluster Orchestration​

Ilum manages heterogeneous Spark clusters from a single control plane:

• Cloud clusters: GKE, EKS, AKS with auto-scaling groups
• On-premise clusters: Bare metal Kubernetes or Hadoop Yarn deployments
• Hybrid architectures: Mixed cloud and on-premise for data sovereignty requirements

Each cluster maintains independent resource quotas, storage backends, and security policies while sharing centralized monitoring and job scheduling.

Comparison with Alternative Solutions​

Video Overview​

Características ​

Spark Cluster Management​

• Kubernetes Operator Integration: Native CRD-based Spark application deployment with pod lifecycle management
• Multi-cluster Control Plane: Centralized management for GKE, EKS, AKS, and on-premise Kubernetes clusters
• Horizontal Pod Autoscaling: Dynamic executor scaling based on CPU/memory metrics and queue depth
• Cotas de recursos : Namespace-level limits for CPU cores, memory, and persistent volume claims

Interactive Computing​

• REST API Endpoints: HTTP interface for Spark session creation, code execution, and result retrieval
• Jupyter Integration: Spark Magic kernels with automatic session binding and DataFrame visualization
• Apache Zeppelin Notebooks: Multi-language interpreters (Scala, Python, SQL) with paragraph-level execution
• Code Groups: Reusable Spark contexts shared across multiple notebook sessions

Storage & Data Formats​

• S3-Compatible Object Storage: MinIO-based distributed storage with S3 API compatibility
• Table Format Support: Delta Lake, Iceberg, Hudi with ACID guarantees and schema evolution
• Catalog Integration: Hive Metastore, AWS Glue, Nessie for metadata management
• Distributed File Systems: HDFS, GCS, Azure Blob Storage, and S3 connectivity

Orchestration & Scheduling​

• Built-in Scheduler: Cron-based job scheduling with dependency management
• Apache Airflow Integration: DAG-based workflow orchestration with Spark operators
• Kestra Support: Event-driven pipelines with Spark task execution
• dbt Core: SQL transformations with Spark as execution engine

Monitoring & Observability​

• Servidor de Histórico do Spark : Job timeline, stage metrics, and executor resource utilization
• Prometheus Integration: Custom metrics for application-level monitoring
• Grafana Dashboards: Pre-configured visualizations for cluster health and job performance
• Loki Log Aggregation: Centralized logging with Promtail collectors
• Linhagem aberta : Data lineage tracking for table-level dependencies

Security & Access Control​

• RBAC Policies: Kubernetes-native role-based access with fine-grained permissions
• OAuth2/OIDC: Integration with Keycloak, Okta, Azure AD for authentication
• TLS/mTLS: Certificate-based encryption for inter-service communication
• LDAP/Active Directory: Enterprise directory service integration
• Network Policies: Pod-to-pod traffic restrictions and egress controls

Explore full feature documentation →| Request new features →

Vantagens ​

Cloud-Native Architecture​

Ilum is designed as a cloud-native first platform with containerized services, declarative configuration, and GitOps-compatible deployment:

• Helm Charts: Parameterized Kubernetes manifests for reproducible deployments
• Container Images: Official images for Spark 3.x with pre-installed connectors (S3, GCS, Azure)
• Custom Resource Definitions: Kubernetes API extensions for Spark application management
• Service Mesh Ready: Compatible with Istio/Linkerd for advanced traffic management

No Vendor Lock-In​

Unlike proprietary platforms, Ilum provides:

• Open APIs: REST and gRPC interfaces following OpenAPI specifications
• Standard Protocols: JDBC/ODBC connectivity, S3 API compatibility, Kafka integration
• Portable Workloads: Spark applications run on any Kubernetes cluster without modification
• Multi-Cloud Support: Deploy across AWS, GCP, Azure without platform-specific dependencies

Hadoop Migration Path​

For organizations migrating from Hadoop/HDFS ecosystems:

• Yarn Compatibility: Run existing Yarn-based Spark jobs without code changes
• HDFS Connector: Direct access to HDFS clusters during migration phases
• Hive Metastore : Reuse existing table metadata and partitioning schemes
• Migração incremental : Gradual transition with hybrid Yarn/Kubernetes deployment

Performance Optimization​

Ilum includes performance enhancements:

• Dynamic Allocation: Automatic executor scaling based on shuffle data and pending tasks
• Adaptive Query Execution (AQE): Runtime optimization for join strategies and partition coalescing
• Columnar Caching: Parquet/ORC in-memory caching with LRU eviction policies
• Network-Aware Scheduling: Pod placement considering data locality and network topology

Enterprise Integration​

Built for enterprise data platforms:

• Apache Kafka : Native Spark Structured Streaming integration with exactly-once semantics
• Fluxo de ar Apache : Managed Airflow instances with Spark operators pre-configured
• Fluxo de ML : Model registry and experiment tracking for machine learning pipelines
• Superset/Tableau: BI tool connectivity via JDBC drivers and load balancers

Read architecture documentation →| View use cases →

Project Roadmap​

Explore planned features and integrations:

• Flink Operator: Stream processing workloads alongside Spark batch jobs
• GPU Scheduling: CUDA-enabled executors for deep learning workloads
• Cost Attribution: Resource usage tracking with cloud billing integration

View full roadmap →| See changelog →

Recursos adicionais ​

• Referência da API : REST API documentation for programmatic access
• Security Guide: Authentication, authorization, and network policies
• Production Deployment: Best practices for production clusters
• Guias do usuário : Step-by-step tutorials for common workflows
